YMW 372917TIn M4-0.70mm Cut Spiral Point Plug 3.0P-5.0P HSSE-V TiN

Part Number: YMW372917TIN

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YMW
SKU: 1173153
Vendor: Sussex Tool and Supply
Call (262) 251-4020 for pricing
YMW M4x0.70MM Cut Spiral Point Plug 3.0P-5.0P HSSE-V TiN D4 Metric Steel Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools
Products specifications
Attribute name Attribute value
Shipping State California
Made In USA NO
Cutter Type Tapping
Tool Material Steel
Cutting Edge Mat HSSE-V
Machine Side Connection Type Tap Collet
Cut Rating Aluminum, Brass, Stainless Steel, <40HRC Steel, Copper, Ductile Iron, Gray Iron
Coating TIN
Overall Length 2.1250 53.98MM
Coolant Thru Non Coolant
Shank/Pilot Dia 0.1680 4.27MM
Flutes/Inserts 3
Type Of Tool Tap
Length Type STANDARD
Performance Rating High Performance
Thread Pitch 0.70MM
Thread Type METRIC
Flute Direction RIGHT
Thread Size M4
Thread Limit D4
Tap Style Cut Spiral Point
Tap Type Plug
Dimension Standard ANSI/ANSI
Tap Drill Range 0.1287 3.27MM - 0.1358 3.45MM
Tap Square 0.1290
Tap Chamfer 3.0P-5.0P
