YG-1 T8R02163 No.4-40.00TPI Roll Form Bottoming 1.5P-2.0P HSS TiN

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-T8R02163
Delivery date: 3-5 days
$11.12

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Coating TiN
Made In USA No
Application Blind Hole Tapping, Bottom Tapping, Tapping, Roll Form Tapping
Package Size 1
Shipping State Illinois
Performance Rating General Performance
Dimensional Specifications
Machine Side Connection Type Tap Collet
Tap Chamfer 1.5P-2.0P
Thread Type NC/UNC
Thread Limit H3/GH3
Drill Range 0.0992 2.52MM - 0.1024 2.60MM
Length Type Standard
Tap Type Bottoming
Thread Pitch 40.00TPI
Tap Style Roll Form
Cut Rating <30HRC Steel, Aluminum, Brass, Copper
Tool Material Steel
Tap Square 0.1100
Dimension Standard ANSI/ANSI
Overall Len 1.8750 47.63MM
Thread Size No.4
Shank/Pilot Dia 0.1410 3.58MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSS
Industry-Specific Applications
Job Shop Yes
