  • YG-1 T7405428 M10-1.50MM STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated
Picture of YG-1 T7405428 M10-1.50MM STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated

YG-1 T7405428 M10-1.50MM STI Bottoming 1.5P-2.0P HSSE-V3 Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-T7405428
Delivery date: 3-5 days
$17.45

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Application Blind Hole Tapping, STI Thread Insert Tapping, Bottom Tapping, Tapping
Package Size 1
Shipping State Illinois
Made In USA No
Performance Rating General Performance
Dimensional Specifications
Cut Rating <30HRC Steel, Aluminum, Ductile Iron, Gray Iron, Stainless Steel
Shank/Pilot Dia 0.3670 9.32MM
Overall Len 3.3750 85.73MM
Machine Side Connection Type Tap Collet
Tap Square 0.2750
Flutes/Inserts 3
Drill Range 0.4134 10.50MM
Thread Type STI-M
Tap Chamfer 1.5P-2.0P
Thread Pitch 1.50MM
Thread Limit D4
Tool Material Steel
Tap Style STI
Length Type Standard
Tap Type Bottoming
Thread Size M10
Dimension Standard ANSI/ANSI
Cutting & Machining Properties
Cutting Edge Mat HSSE-V3
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
