  • YG-1 T7405427 M10-1.50MM STI Plug 4.0P-5.0P HSSE-V3 Uncoated
Picture of YG-1 T7405427 M10-1.50MM STI Plug 4.0P-5.0P HSSE-V3 Uncoated

YG-1 T7405427 M10-1.50MM STI Plug 4.0P-5.0P HSSE-V3 Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-T7405427
Delivery date: 3-5 days
$17.45

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Shipping State Illinois
Application STI Thread Insert Tapping, Through Hole Tapping, Plug Tapping, Tapping
Performance Rating General Performance
Package Size 1
Dimensional Specifications
Machine Side Connection Type Tap Collet
Tap Square 0.2750
Tap Chamfer 4.0P-5.0P
Thread Limit D4
Length Type Standard
Shank/Pilot Dia 0.3670 9.32MM
Overall Len 3.3750 85.73MM
Drill Range 0.4134 10.50MM
Tap Type Plug
Thread Pitch 1.50MM
Tool Material Steel
Tap Style STI
Thread Size M10
Dimension Standard ANSI/ANSI
Cut Rating <30HRC Steel, Aluminum, Ductile Iron, Gray Iron, Stainless Steel
Flutes/Inserts 3
Thread Type STI-M
Cutting & Machining Properties
Cutting Edge Mat HSSE-V3
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
