Picture of YG-1 T7405317 M6-1.00MM STI Plug 4.0P-5.0P HSSE-V3 Uncoated

YG-1 T7405317 M6-1.00MM STI Plug 4.0P-5.0P HSSE-V3 Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-T7405317
Delivery date: 3-5 days
$10.04

Cutting Edge Definition

Vanadium: increases wear resistance of finishing tools. • Cobalt: enables increased hardening temperatures and improves heat resistance. All types of HSS contain significant amounts of carbon, which reacts with the refractory metals to form hard carbides, which increase wear resistance and hot hardness.

Products specifications
Attribute name Attribute value
General Product Information
Application Tapping, STI Thread Insert Tapping, Through Hole Tapping, Plug Tapping
Performance Rating General Performance
Shipping State Illinois
Made In USA No
Package Size 1
Dimensional Specifications
Dimension Standard ANSI/ANSI
Flutes/Inserts 3
Drill Range 0.2480 6.30MM
Tool Material Steel
Shank/Pilot Dia 0.3180 8.08MM
Tap Style STI
Tap Square 0.2380
Tap Type Plug
Thread Size M6
Thread Limit D3
Overall Len 2.7200 69.09MM
Length Type Standard
Thread Pitch 1.00MM
Machine Side Connection Type Tap Collet
Thread Type STI-M
Tap Chamfer 4.0P-5.0P
Cut Rating <30HRC Steel, Aluminum, Ductile Iron, Gray Iron, Stainless Steel
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSSE-V3
Industry-Specific Applications
Job Shop Yes
