YG-1 E5018902S DIA 3/8" SH 0.3750 LOC 1.50 OAL 6.00 End Mill Standard Flute High Helix Carbide Uncoated Single End Ball Nose Generic

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-E5018902S
Delivery date: 3-5 days
$46.21

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Ball Slot Milling, Profile Milling, Copy Milling, Ball Milling, Side Milling
Package Size 1
Shipping State Illinois
Performance Rating General Performance
Made In USA Yes
Dimensional Specifications
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Style Carbide Ball Finisher
Machine Side Connection Size 0.3750 9.53MM
Flutes/Inserts 2
Tool Material Carbide
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Length Of Cut 1.5000 38.10MM
Single/Double End Single End
Shank/Pilot Dia 0.3750 9.53MM - 3/8
Cutter Dia 0.3750 9.53MM - 3/8
End Of Tool Shape Ball Nose
Overall Len 6.0000 152.40MM
Length Type Extra Long
Helix Angle 30°
Cutting & Machining Properties
Center Cutting Yes
Coolant Thru No
Cutting Edge Mat Carbide
Industry-Specific Applications
Job Shop Yes
