YG-1 38602 DIA 3/32 SH 0.2500 LOC 0.1250 OAL 2.3750 End Mill Standard Flute Standard Helix Carbide Uncoated Single End Ball Nose Alu-Power End Mill

Need Assistance or Service? Please call 262-251-4020

Manufacturer: YG-1
SKU: YG-38602
Delivery date: 3-5 days
$15.83

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Copy Milling, Ball Milling, Ball Slot Milling, Side Milling, Profile Milling
Performance Rating High Performance
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Cut Rating Aluminum, Graphite, Plastic
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.2500 6.35MM
Length Of Cut 0.1250 3.18MM
Inch/Metric Inch
End Of Tool Shape Ball Nose
Shank/Pilot Dia 0.2500 6.35MM - 1/4 - E
Cutter Dia 0.0938 2.38MM - 3/32
Neck Length 0.1870 4.75MM
Length Type Standard / With Neck
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Helix Angle 40°
Overall Len 2.3750 60.33MM
Flutes/Inserts 3
Cutting & Machining Properties
Center Cutting Yes
Cutting Edge Mat Carbide
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
