Picture of XACTFORM PO 32-32-27NL Boring Bar Iso Thread Boring Bar 1.141 Shank

XACTFORM PO 32-32-27NL Boring Bar Iso Thread Boring Bar 1.141 Shank

ANSI: PO 32-32-27NL

ISO: PO 32-32-27NL

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC25034
Delivery date: 3-5 days
$202.95
Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert Application General Purpose
Application Int.Groove Threading, Int.Threading
Insert/Tool Tool
Shipping State Florida
Insert Type Positive
Made In USA No
Dimensional Specifications
Insert Size Ic 27
Tool Material Steel
Machine Side Connection Type Boring Bar
Machine Side Connection Size 1.1417 29.00MM
Shank/Pilot Dia 1.1417 29.00MM
Min Bore 1.5748
Neck Dia 1.2598
Overall Len 9.8425 250.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style ISO
Inter/Extern Internal
Seat/Nest YE5
Hand R/L Left
