XACTFORM 74226 Indexable Thread Mill 12.00TPI External Dia 0.827 OAL

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC74226
Delivery date: 3-5 days
$72.89

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Performance Rating High Performance
Grade K20C
Shipping State Florida
Application Thread Milling
Made In USA No
Package Size 2
Coating TiN
Dimensional Specifications
Cut Rating <40HRC, Stainless, Iron, High Temp
Overall Len 0.8270 21.01MM
Length Of Cut 0.8270 21.01MM
Thread Pitch 12.00TPI
Cutting & Machining Properties
Cutting Edge Mat Carbide
Inter/Extern External
Industry-Specific Applications
Automotive Yes
Medical Yes
Energy Yes
Aerospace Yes
Job Shop Yes
