XACTFORM 74153 Indexable Thread Mill 14.00TPI Internal Dia 1.575 OAL

Need Assistance or Service? Please call 262-251-4020

Manufacturer: XACTFORM
SKU: XAC74153
Delivery date: 3-5 days
$134.49

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Grade K20C
Performance Rating High Performance
Made In USA No
Coating TiN
Application Thread Milling
Package Size 2
Shipping State Florida
Dimensional Specifications
Thread Pitch 14.00TPI
Cut Rating <40HRC, Stainless, Iron, High Temp
Length Of Cut 1.5750 40.01MM
Overall Len 1.5750 40.01MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Inter/Extern Internal
Industry-Specific Applications
Energy Yes
Aerospace Yes
Medical Yes
Automotive Yes
Job Shop Yes
