WIDIN WAF303060 DIA 6MM SH 0.2362 LOC 0.6299 OAL 2.3622 End Mill Carbide Uncoated Single End Square Sharp ALU-WAVE

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIN
SKU: WIDWAF303060
Delivery date: 3-5 days
$27.65

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Face Milling, Slot Milling
Package Size 1
Performance Rating High Performance
Made In USA No
Shipping State Illinois
Dimensional Specifications
Inch/Metric Metric
Cut Rating Aluminum, Graphite, Plastic
Tool Material Carbide
Shank/Pilot Dia 0.2362 6.00MM
Cutter Style Carbide Rougher
Cutter Dia 0.2362 6.00MM
Length Of Cut 0.6300 16.00MM
Single/Double End Single End
Machine Side Connection Size 0.2362 6.00MM
Length Type Standard
Helix Angle 38°
Flutes/Inserts 3
End Of Tool Shape Square
Overall Len 2.3622 60.00MM
Machine Side Connection Type Weldon
Cutting & Machining Properties
Coolant Thru No
Center Cutting Yes
Cutting Edge Mat Carbide
Industry-Specific Applications
Agricultural YES
Energy Yes
Job Shop Yes
