WIDIN WAE303180 DIA 18MM SH 0.7087 LOC 1.9291 OAL 3.9370 End Mill Standard Flute High Helix Carbide Uncoated Single End Square Sharp ALU-WAVE

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIN
SKU: WIDWAE303180
Delivery date: 3-5 days
$172.68

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Performance Rating High Performance
Application Side Milling, Face Milling, Slot Milling
Package Size 1
Made In USA No
Shipping State Illinois
Dimensional Specifications
Length Of Cut 1.9291 49.00MM
Helix Angle 45°
Cut Rating Aluminum, Graphite, Plastic
Tool Material Carbide
Machine Side Connection Type Cylindrical
Cutter Style Carbide Finisher
Shank/Pilot Dia 0.7087 18.00MM
Inch/Metric Metric
Cutter Dia 0.7087 18.00MM
Flutes/Inserts 3
End Of Tool Shape Square
Single/Double End Single End
Length Type Extra Long
Machine Side Connection Size 0.7087 18.00MM
Overall Len 3.9370 100.00MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
