WIDIN NDPR128 12.80MM DIA 140° Point 2 Flute 5.5-7.5XD Drill

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIN
SKU: WIDNDPR128
Delivery date: 3-5 days
$72.57

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Application Dilling, Drilling Flood Coolant
Shipping State Illinois
Package Size 1
Coating PVD
Dimensional Specifications
Flute Length 2.4800 62.99MM
Dia Deep 5.5XD-7.5XD
Included Angle 140°
Cut Rating <40HRC Steel, Ductile Iron, Gray Iron
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 0.5118 13.00MM
Flutes/Inserts 2
Overall Len 4.0157 102.00MM
Cutter Dia 0.5040 12.80MM
Cut Dia Min 0.5040 12.80MM
Shank/Pilot Dia 0.5118 13.00MM
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Industry-Specific Applications
Automotive Yes
Job Shop Yes
