WIDIA/KENNAMETAL VTSPO7519 M20-2.50MM Cut Spiral Point Plug 3.5P-5.0P HSSE Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WIDVTSPO7519
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Products specifications
Attribute name Attribute value
General Product Information
Application Plug Tapping, Cut Tapping, Tapping, Through Hole Tapping
Made In USA No
Performance Rating High Performance
Shipping State Ohio
Package Size 1
Dimensional Specifications
Dimension Standard JIS
Thread Pitch 2.50MM
Thread Type Metric
Cut Rating <40HRC Steel, Aluminum, Brass, Copper, Stainless Steel
Flute Direction R - Right
Overall Len 4.1300 104.90MM
Length Type Standard
Flutes/Inserts 3
Thread Size M20
Drill Range 0.6850 17.40MM - 0.7106 18.05MM
Tap Type Plug
Tap Chamfer 3.5P-5.0P
Thread Limit 6H
Machine Side Connection Type Tap Collet
Tap Square 0.4720
Tap Style Cut Spiral Point
Tool Material Steel
Shank/Pilot Dia 0.5906 15.00MM
Cutting & Machining Properties
Cutting Edge Mat HSSE
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
