Picture of WIDIA/KENNAMETAL E32USCLCR12 80.0° Insert Boring Bar 1.259

WIDIA/KENNAMETAL E32USCLCR12 80.0° Insert Boring Bar 1.259

ANSI: E32USCLCR12

ISO: E32U-SCLCR12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2023632
Delivery date: 3-5 days
$1,805.47

Details

WIDIA LR SERIES BORING BAR

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Pennsylvania
Insert Type Positive
Application Int.Turning
Dimensional Specifications
Insert Size Ic 12 "43"
Overall Len 13.7795 350.00MM
Tool Material Carbide
Min Bore 1.5748
Shank/Pilot Dia 1.2598 32.00MM
Flutes/Inserts 1
Machine Side Connection Type Boring Bar
Machine Side Connection Size 1.2598 32.00MM
Lead Angle 95°
Cutting & Machining Properties
Inter/Extern Internal
Insert Style CC
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Right
Coolant Thru Yes
Cool Sply Type 1/4-18 NPT
