Picture of WIDIA/KENNAMETAL CCBI31260R Carbide 80.0° Insert Boring Bar 0.312

WIDIA/KENNAMETAL CCBI31260R Carbide 80.0° Insert Boring Bar 0.312

ANSI: CCBI31260R

ISO: CCBI31260R

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2832234
Delivery date: 3-5 days
$330.85

Features And Benefits

High desity carbided used to dampen vibration. Great for long reach boring.

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Shipping State Pennsylvania
Insert Application General Purpose
Made In USA No
Insert Type Positive
Package Size 1
Application Int.Turning
Dimensional Specifications
Insert Size Ic 12
Flutes/Inserts 1
Tool Material Carbide
Min Bore 0.3560
Machine Side Connection Type Boring Bar
Machine Side Connection Size 0.3125 7.94MM
Shank/Pilot Dia 0.3125 7.94MM - 5/16
Overall Len 6.0000 152.40MM
Lead Angle 90°
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Right
Inter/Extern Internal
Insert Style CD
