Picture of WIDIA/KENNAMETAL A25TPCLNR12 80.0° Insert Boring Bar 0.984

WIDIA/KENNAMETAL A25TPCLNR12 80.0° Insert Boring Bar 0.984

ANSI: A25TPCLNR12

ISO: A25TPCLNR12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID3883468
Delivery date: 3-5 days
$250.45

Details

KENLEVER STEEL BAR

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert/Tool Tool
Shipping State Pennsylvania
Application Int.Turning
Insert Application General Purpose
Insert Type Negative
Made In USA No
Dimensional Specifications
Tool Material Steel
Min Bore 1.2600
Shank/Pilot Dia 0.9843 25.00MM
Flutes/Inserts 1
Insert Size Ic 12 "43"
Lead Angle 95°
Machine Side Connection Type Boring Bar
Machine Side Connection Size 0.9843 25.00MM
Overall Len 11.8110 300.00MM
Cutting & Machining Properties
Hand R/L Right
Insert Style CN
Cool Sply Type 1/4-18 NPT
Coolant Thru Yes
Inter/Extern Internal
Insert Shape/Cutter Pocket Shape 80.0°
