WIDIA/KENNAMETAL A24UMDUNR4 55.0° Insert Boring Bar 1.500

ANSI: A24UMDUNR4

ISO: A24UMDUNR4

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2951412
Delivery date: 3-5 days
$347.93

Details

WIDIA LW SERIES BAR

Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Pennsylvania
Package Size 1
Application Int.Turning
Insert/Tool Tool
Dimensional Specifications
Machine Side Connection Type Boring Bar
Machine Side Connection Size 1.5000 38.10MM
Clearance Angle 20.0°
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Lead Angle 93°
Tool Material Steel
Insert Size Ic 12 "43"
Overall Len 14.0000 355.60MM
Flutes/Inserts 1
Min Bore 2.0000
Cutting & Machining Properties
Cool Sply Type 1/4-18 NPT
Inter/Extern Internal
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DN
Coolant Thru Yes
Hand R/L Right
