Picture of WIDIA/KENNAMETAL A16RSDUCL11 55.0° Insert Boring Bar 0.629

WIDIA/KENNAMETAL A16RSDUCL11 55.0° Insert Boring Bar 0.629

ANSI: A16RSDUCL11

ISO: A16RSDUCL11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID3883295
Delivery date: 3-5 days
$112.84

Details

LR SERIES BAR

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Made In USA No
Insert/Tool Tool
Insert Application General Purpose
Shipping State Pennsylvania
Insert Type Positive
Application Int.Turning
Dimensional Specifications
Min Bore 0.7874
Insert Size Ic 11 "32"
Machine Side Connection Type Boring Bar
Overall Len 7.8740 200.00MM
Flutes/Inserts 1
Clearance Angle 30.0°
Lead Angle 93°
Tool Material Steel
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cutting & Machining Properties
Inter/Extern Internal
Insert Style DC
Coolant Thru Yes
Hand R/L Left
Insert Shape/Cutter Pocket Shape 55.0°
Cool Sply Type 1/8-27 NPT
