Picture of WIDIA/KENNAMETAL A10SSCLCR2 80.0° Insert Boring Bar 0.625

WIDIA/KENNAMETAL A10SSCLCR2 80.0° Insert Boring Bar 0.625

ANSI: A10SSCLCR2

ISO: A10SSCLCR2

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID2951388
Delivery date: 3-5 days
$130.20

Details

WIDIA SCREW-ON STEEL BAR

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Int.Turning
Made In USA No
Insert Application General Purpose
Shipping State Pennsylvania
Insert/Tool Tool
Package Size 1
Dimensional Specifications
Lead Angle 95°
Overall Len 10.0000 254.00MM
Flutes/Inserts 1
Insert Size Ic 06 "21"
Tool Material Steel
Machine Side Connection Type Boring Bar
Min Bore 0.7700
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Machine Side Connection Size 0.6250 15.88MM
Cutting & Machining Properties
Inter/Extern Internal
Insert Shape/Cutter Pocket Shape 80.0°
Hand R/L Right
Coolant Thru Yes
Cool Sply Type 1/8-27 NPT
Insert Style CC
