Picture of WIDIA/KENNAMETAL A10KSCLCR06 80.0° Insert Boring Bar 0.390

WIDIA/KENNAMETAL A10KSCLCR06 80.0° Insert Boring Bar 0.390

ANSI: A10KSCLCR06

ISO: A10KSCLCR06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID3883283
Delivery date: 3-5 days
$133.67

Details

LR SERIES BAR

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Insert/Tool Tool
Insert Type Positive
Application Int.Turning
Package Size 1
Insert Application General Purpose
Shipping State Pennsylvania
Dimensional Specifications
Flutes/Inserts 1
Lead Angle 95°
Machine Side Connection Size 0.3902 9.91MM
Min Bore 0.5120
Insert Size Ic 06 "21"
Tool Material Steel
Machine Side Connection Type Boring Bar
Shank/Pilot Dia 0.3900 9.91MM
Overall Len 4.9210 124.99MM
Cutting & Machining Properties
Coolant Thru Yes
Inter/Extern Internal
Hand R/L Right
Insert Style CC
Insert Shape/Cutter Pocket Shape 80.0°
