WIDIA/KENNAMETAL 18265 M12-1.75MM Roll Form Bottoming 1.0P-2.0P HSSE Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: WIDIA/KENNAMETAL
SKU: WID18265
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Products specifications
Attribute name Attribute value
General Product Information
Application Bottom Tapping, Roll Form Tapping, Tapping, Blind Hole Tapping
Performance Rating General Performance
Shipping State Ohio
Made In USA No
Package Size 1
Dimensional Specifications
Thread Size M12
Dimension Standard ANSI/ANSI
Overall Len 3.3800 85.85MM
Tool Material Steel
Tap Type Bottoming
Thread Pitch 1.75MM
Thread Limit D11
Drill Range 0.4374 11.11MM - 0.4469 11.35MM
Tap Square 0.2760
Flute Direction R - Right
Length Type Standard
Tap Style Roll Form
Machine Side Connection Type Tap Collet
Tap Chamfer 1.0P-2.0P
Thread Type Metric
Cut Rating <40HRC Steel, Aluminum, Brass, Copper, Stainless Steel
Shank/Pilot Dia 0.3670 9.32MM
Cutting & Machining Properties
Cutting Edge Mat HSSE
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
