VIKING 9061 #77 Cobalt Drill Jobber Length Gold Coated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: VIKING
SKU: VIK09061
Delivery date: 3-5 days
$4.84

Cutting Edge Definition

Cobalt steel is a type of high-speed alloy steel used primarily for cutting tools. Introduced to manufacturers in 1900, high-speed steel, containing a mixture of tungsten, chromium, and trace amounts of carbon, enabled manufacturers to double or even triple their production.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert and reduces friction. Use it on cutting tools, punches, dies and injection mold components to improve tool life two to ten times, or more, over uncoated tools.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Package Size 12
Coating TiN
Application Drilling
Shipping State Minnesota
Dimensional Specifications
Cut Rating <30HRC Steel, Aluminum, Stainless Steel
Tool Material Cobalt
Machine Side Connection Size 0.0180 0.46MM
Drill Length Type Jobber
Cutter Dia 0.0180 0.46MM - #77
Cut Dia Min 0.0180 0.46MM - #77
Shank/Pilot Dia 0.0180 0.46MM - #77
Flutes/Inserts 2
Flute Length 0.1880 4.78MM
Overall Len 0.8750 22.23MM
Included Angle 135°
Machine Side Connection Type Cylindrical
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Cobalt
Industry-Specific Applications
Job Shop Yes
Contractor Yes
