Picture of VIKING 79850 29/64 Cobalt Drill Jobber Length TIN

VIKING 79850 29/64 Cobalt Drill Jobber Length TIN

Need Assistance or Service? Please call 262-251-4020

Manufacturer: VIKING
SKU: VIK79850
Delivery date: 3-5 days
$18.11

Cutting Edge Definition

Cobalt steel is a type of high-speed alloy steel used primarily for cutting tools. Introduced to manufacturers in 1900, high-speed steel, containing a mixture of tungsten, chromium, and trace amounts of carbon, enabled manufacturers to double or even triple their production.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Coating TiN
Package Size 3
Shipping State Minnesota
Application Drilling
Made In USA Yes
Dimensional Specifications
Machine Side Connection Size 0.4531 11.51MM
Flute Length 4.1880 106.38MM
Drill Length Type Jobber
Flutes/Inserts 2
Machine Side Connection Type Cylindrical
Included Angle 135°
Cut Dia Min 0.4531 11.51MM - 29/64
Cut Rating <30HRC Steel, Aluminum, Stainless Steel
Shank/Pilot Dia 0.4531 11.51MM - 29/64
Cutter Dia 0.4531 11.51MM - 29/64
Tool Material Cobalt
Overall Len 5.6250 142.88MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Cobalt
Industry-Specific Applications
Job Shop Yes
Contractor Yes
