VIKING 37243 9/32 Cobalt Drill Screw Machine Length Gold Coated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: VIKING
SKU: VIK37243
Delivery date: 3-5 days
$7.91

Cutting Edge Definition

Cobalt steel is a type of high-speed alloy steel used primarily for cutting tools. Introduced to manufacturers in 1900, high-speed steel, containing a mixture of tungsten, chromium, and trace amounts of carbon, enabled manufacturers to double or even triple their production.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert and reduces friction. Use it on cutting tools, punches, dies and injection mold components to improve tool life two to ten times, or more, over uncoated tools.

Products specifications
Attribute name Attribute value
General Product Information
Application Drilling
Shipping State Minnesota
Coating TiN
Package Size 6
Made In USA Yes
Dimensional Specifications
Shank/Pilot Dia 0.2810 7.14MM - 9/32 - K
Included Angle 135°
Tool Material Cobalt
Machine Side Connection Type Cylindrical
Overall Len 2.6875 68.26MM
Machine Side Connection Size 0.2813 7.15MM
Flute Length 1.5000 38.10MM
Cut Rating <40HRC Steel, High Temp, Stainless Steel
Cutter Dia 0.2812 7.14MM - 9/32
Cut Dia Min 0.2810 7.14MM - 9/32 - K
Flutes/Inserts 2
Drill Length Type Screw
Cutting & Machining Properties
Cutting Edge Mat Cobalt
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
Contractor Yes
