VIKING 37203 7/32 Cobalt Drill Screw Machine Length Gold Coated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: VIKING
SKU: VIK37203
Delivery date: 3-5 days
$6.16

Cutting Edge Definition

Cobalt steel is a type of high-speed alloy steel used primarily for cutting tools. Introduced to manufacturers in 1900, high-speed steel, containing a mixture of tungsten, chromium, and trace amounts of carbon, enabled manufacturers to double or even triple their production.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert and reduces friction. Use it on cutting tools, punches, dies and injection mold components to improve tool life two to ten times, or more, over uncoated tools.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 6
Made In USA Yes
Shipping State Minnesota
Coating TiN
Application Drilling
Dimensional Specifications
Flutes/Inserts 2
Drill Length Type Screw
Machine Side Connection Type Cylindrical
Cutter Dia 0.2188 5.56MM - 7/32
Tool Material Cobalt
Machine Side Connection Size 0.2188 5.56MM
Shank/Pilot Dia 0.2187 5.55MM - 7/32
Cut Rating <40HRC Steel, High Temp, Stainless Steel
Overall Len 2.3750 60.33MM
Flute Length 1.2500 31.75MM
Cut Dia Min 0.2188 5.56MM - 7/32
Included Angle 135°
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Cobalt
Industry-Specific Applications
Job Shop Yes
Contractor Yes
