VIKING 3420 #24 HSS Drill Jobbers Length Uncoated

Need Assistance or Service? Please call 262-251-4020

Manufacturer: VIKING
SKU: VIK03420
Delivery date: 3-5 days
$1.03

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Package Size 12
Shipping State Minnesota
Application Drilling
Dimensional Specifications
Overall Len 3.1250 79.38MM
Flute Length 2.0000 50.80MM
Cutter Dia 0.1520 3.86MM - #24
Cut Dia Min 0.1520 3.86MM - #24
Machine Side Connection Type Cylindrical
Included Angle 118°
Shank/Pilot Dia 0.1520 3.86MM - #24
Cut Rating Aluminum, Brass, Plastic, Copper
Machine Side Connection Size 0.1520 3.86MM
Tool Material High Speed Steel
Flutes/Inserts 2
Drill Length Type Jobber
Cutting & Machining Properties
Cutting Edge Mat HSS
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
Contractor Yes
