TUNGALOY VTS075L880S10UC DIA 39/64 SH 0.7500 LOC 6.30 OAL 8.80 Replacable Head Acc. Straight Shank/Taper Neck Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6864018
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Circle Segment, Side Milling, Slot Milling, Copy Milling, Feed Milling, Dovetail Milling, Face Milling, Groove Milling, Profile Milling
Package Size 1
Performance Rating High Performance
Made In USA No
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Cutter Style Screw On Tungaloy Shank
Cutter Dia 0.6094 15.48MM - 39/64
Length Type Standard
Dimension Description 0.609 x 0.750 x 6.300 x 8.800
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Length Of Cut 6.3000 160.02MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 8.8000 223.52MM
Single/Double End Single End
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru No
Center Cutting No
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
Agricultural YES
Medical Yes
Energy Yes
