TUNGALOY VTS075L700S08UC DIA 12MM SH 0.7500 LOC 4.00 OAL 7.00 Replacable Head Acc. Straight Shank/Taper Neck Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6863987
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Performance Rating High Performance
Made In USA No
Application Side Milling, Circle Segment, Groove Milling, Profile Milling, Slot Milling, Copy Milling, Feed Milling, Face Milling, Dovetail Milling
Shipping State Illinois
Package Size 1
Dimensional Specifications
Cutter Dia 0.4724 12.00MM
Cutter Style Screw On Tungaloy Shank
Length Type Standard
Length Of Cut 4.0000 101.60MM
Tool Material Steel
Dimension Description 0.472 x 0.750 x 4.000 x 7.000
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Overall Len 7.0000 177.80MM
Single/Double End Single End
Machine Side Connection Size 0.7500 19.05MM
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting No
Industry-Specific Applications
Automotive Yes
Job Shop Yes
Medical Yes
Agricultural YES
Energy Yes
Aerospace Yes
Mold Yes
