TUNGALOY VSSD20L200S12-C DIA 18.30MM SH 0.7874 LOC 4.7244 OAL 7.87Replacable Head Acc. Straight Neck/Cylicrical Shank Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6859163
Delivery date: 3-5 days
$1,100.90

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Shipping State Illinois
Application Face Milling, Groove Milling, Profile Milling, Slot Milling, Dovetail Milling, Copy Milling, Circle Segment, Side Milling, Feed Milling
Performance Rating High Performance
Package Size 1
Dimensional Specifications
Length Type Standard
Tool Material Steel
Length Of Cut 4.7244 120.00MM
Shank/Pilot Dia 0.7874 20.00MM
Single/Double End Single End
Dimension Description 0.720 x 0.787 x 4.724 x 7.874
Cutter Dia 0.7204 18.30MM
Cutter Style Screw On Tungaloy Shank
Machine Side Connection Size 0.7874 20.00MM
Machine Side Connection Type Cylindrical
Overall Len 7.8740 200.00MM
Inch/Metric Metric
Cutting & Machining Properties
Cutting Edge Mat Carbide
Center Cutting No
Coolant Thru No
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
Agricultural YES
Medical Yes
Energy Yes
