TUNGALOY VSSD10L090S06-C DIA 9.60MM SH 0.3937 LOC 1.5748 OAL 3.543Replacable Head Acc. Straight Neck/Cylicrical Shank Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6859172
Delivery date: 3-5 days
$317.15

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Made In USA No
Shipping State Illinois
Application Circle Segment, Side Milling, Dovetail Milling, Feed Milling, Copy Milling, Face Milling, Groove Milling, Profile Milling, Slot Milling
Performance Rating High Performance
Dimensional Specifications
Overall Len 3.5433 90.00MM
Inch/Metric Metric
Length Type Standard
Length Of Cut 1.5748 40.00MM
Tool Material Steel
Machine Side Connection Size 0.3937 10.00MM
Dimension Description 0.378 x 0.394 x 1.575 x 3.543
Cutter Dia 0.3779 9.60MM
Cutter Style Screw On Tungaloy Shank
Shank/Pilot Dia 0.3937 10.00MM
Machine Side Connection Type Cylindrical
Single/Double End Single End
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting No
Industry-Specific Applications
Aerospace Yes
Automotive Yes
Job Shop Yes
Mold Yes
Agricultural YES
Medical Yes
Energy Yes
