TUNGALOY VSSD10L070S06-C DIA 9.60MM SH 0.3937 LOC 0.7874 OAL 2.755Replacable Head Acc. Straight Neck/Cylicrical Shank Carbide Single End TUNG MEISTER

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6859158
Delivery date: 3-5 days
$317.15

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Products specifications
Attribute name Attribute value
General Product Information
Application Copy Milling, Feed Milling, Face Milling, Groove Milling, Profile Milling, Circle Segment, Side Milling, Slot Milling, Dovetail Milling
Performance Rating High Performance
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Machine Side Connection Type Cylindrical
Single/Double End Single End
Tool Material Steel
Machine Side Connection Size 0.3937 10.00MM
Length Type Standard
Cutter Dia 0.3779 9.60MM
Length Of Cut 0.7874 20.00MM
Cutter Style Screw On Tungaloy Shank
Inch/Metric Metric
Dimension Description 0.378 x 0.394 x 0.787 x 2.756
Shank/Pilot Dia 0.3937 10.00MM
Overall Len 2.7560 70.00MM
Cutting & Machining Properties
Center Cutting No
Coolant Thru No
Cutting Edge Mat Carbide
Industry-Specific Applications
Agricultural YES
Medical Yes
Energy Yes
Aerospace Yes
Job Shop Yes
Mold Yes
Automotive Yes
