Picture of TUNGALOY TRLG23.00X1500-U05 23mm Drill body for gun Drill machine

TUNGALOY TRLG23.00X1500-U05 23mm Drill body for gun Drill machine

ISO: TRLG23.00X1500-U05

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN4890264
Delivery date: 3-5 days
$1,480.85

Cutting Edge Definition

Tool steel is any of various carbon steels and alloy steels that are particularly well-suited to be made into tools and tooling, including cutting tools, dies, hand tools, knives, and others.

Products specifications
Attribute name Attribute value
General Product Information
Application Drilling, Multi Insert Drilling
Shipping State Illinois
Package Size 1
Made In USA No
Dimensional Specifications
Tool Material Steel
Machine Side Connection Size 1.2520 31.80MM
Cutter Dia 0.9055 23.00MM
Overall Len 59.1890 1503.40MM
Cut Dia Min 0.9055 23.00MM
Shank/Pilot Dia 1.2520 31.80MM
Flute Length 55.0940 1399.39MM
Machine Side Connection Type Boring Bar,Weldon
Flutes/Inserts 1
Dia Deep 24.0XD
Cutting & Machining Properties
Coolant Thru Yes
Cutting Edge Mat Steel
Industry-Specific Applications
Agricultural YES
Job Shop Yes
Mold Yes
