  • TUNGALOY TRLG13.00X1650-23 13mm Drill body for gun Drill machine
Picture of TUNGALOY TRLG13.00X1650-23 13mm Drill body for gun Drill machine

TUNGALOY TRLG13.00X1650-23 13mm Drill body for gun Drill machine

ISO: TRLG13.00X1650-23

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN4847336
Delivery date: 3-5 days
$902.15

Cutting Edge Definition

Tool steel is any of various carbon steels and alloy steels that are particularly well-suited to be made into tools and tooling, including cutting tools, dies, hand tools, knives, and others.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Application Drilling, Multi Insert Drilling
Shipping State Illinois
Package Size 1
Dimensional Specifications
Flute Length 62.0390 1575.79MM
Cutter Dia 0.5118 13.00MM
Shank/Pilot Dia 0.9843 25.00MM
Flutes/Inserts 1
Tool Material Steel
Machine Side Connection Size 0.9843 25.00MM
Cut Dia Min 0.5118 13.00MM
Overall Len 65.0315 1651.80MM
Dia Deep 22.0XD
Machine Side Connection Type Boring Bar,Weldon
Cutting & Machining Properties
Cutting Edge Mat Steel
Coolant Thru Yes
Industry-Specific Applications
Job Shop Yes
Agricultural YES
Mold Yes
