Picture of TUNGALOY TPQ18R600U0200A09 Milling Cutter 90.0° 6.000 Cutter Diameter Shell Arbor 2.0000 9 Flute

TUNGALOY TPQ18R600U0200A09 Milling Cutter 90.0° 6.000 Cutter Diameter Shell Arbor 2.0000 9 Flute

ANSI: TPQ18R600U0200A09

ISO: TPQ18R600U0200A09

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861316
Delivery date: 3-5 days
$1,689.10

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Package Size 1
Application Face Milling, Slot Milling, Side Milling
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Tool Material Steel
Cutter Dia 6.0000 152.40MM
Flutes/Inserts 9
Cut Dia Max 6.0000 152.40MM
Insert Size Ic 18
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.6290
Machine Side Connection Size 2.0000 50.80MM
Cut Dia Min 6.0000 152.40MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Hand R/L Right
Insert Style LQ
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7000219
