Picture of TUNGALOY TPQ18R160M50.8-09 Milling Cutter 90.0° 6.299 Cutter Diameter Shell Arbor 2.0000 9 Flute

TUNGALOY TPQ18R160M50.8-09 Milling Cutter 90.0° 6.299 Cutter Diameter Shell Arbor 2.0000 9 Flute

ANSI: TPQ18R160M50.8-09

ISO: TPQ18R160M50.8-09

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861241
Delivery date: 3-5 days
$1,689.10

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Application Side Milling, Face Milling, Slot Milling
Dimensional Specifications
Cut Dia Min 6.2990 159.99MM
Tool Material Steel
Cutter Dia 6.2990 159.99MM
Insert Size Ic 18
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.6290
Cut Dia Max 6.2990 159.99MM
Machine Side Connection Size 2.0000 50.80MM
Flutes/Inserts 9
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Hand R/L Right
Insert Style LQ
Fasteners & Connectors
Insert Screw 7000219
