Picture of TUNGALOY TPQ11R400U0150A12 Milling Cutter 90.0° 4.000 Cutter Diameter Shell Arbor 1.5000 12 Flute

TUNGALOY TPQ11R400U0150A12 Milling Cutter 90.0° 4.000 Cutter Diameter Shell Arbor 1.5000 12 Flute

ANSI: TPQ11R400U0150A12

ISO: TPQ11R400U0150A12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861300
Delivery date: 3-5 days
$1,240.15

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Package Size 1
Application Face Milling, Slot Milling, Side Milling
Insert/Tool Tool
Shipping State Illinois
Insert Type Negative
Made In USA No
Dimensional Specifications
Insert Size Ic 11
Cut Dia Max 4.0000 101.60MM
Machine Side Connection Size 1.5000 38.10MM
Cutter Dia 4.0000 101.60MM
Flutes/Inserts 12
Cut Dia Min 4.0000 101.60MM
Tool Material Steel
Depth Of Cut Max 0.3540
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Hand R/L Right
Insert Style LQ
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7002495
