Picture of TUNGALOY TPQ11R200U0075A06 Milling Cutter 90.0° 2.000 Cutter Diameter Shell Arbor 0.7500 6 Flute

TUNGALOY TPQ11R200U0075A06 Milling Cutter 90.0° 2.000 Cutter Diameter Shell Arbor 0.7500 6 Flute

ANSI: TPQ11R200U0075A06

ISO: TPQ11R200U0075A06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861287
Delivery date: 3-5 days
$625.90

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Application Side Milling, Slot Milling, Face Milling
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Depth Of Cut Max 0.3540
Cut Dia Min 2.0000 50.80MM
Cut Dia Max 2.0000 50.80MM
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 11
Cutter Dia 2.0000 50.80MM
Flutes/Inserts 6
Cutting & Machining Properties
Coolant Thru Yes
Hand R/L Right
Insert Style LQ
Insert Shape/Cutter Pocket Shape Parallelogram
Fasteners & Connectors
Insert Screw 7002495
