Picture of TUNGALOY TPQ11R050M22.0E06 Milling Cutter 90.0° 1.967 Cutter Diameter Shell Arbor 0.8661 6 Flute

TUNGALOY TPQ11R050M22.0E06 Milling Cutter 90.0° 1.967 Cutter Diameter Shell Arbor 0.8661 6 Flute

ANSI: TPQ11R050M22.0E06

ISO: TPQ11R050M22.0E06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861301
Delivery date: 3-5 days
$625.90

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Application Side Milling, Face Milling, Slot Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Depth Of Cut Max 0.3540
Cut Dia Max 1.9690 50.01MM
Cutter Dia 1.9670 49.96MM
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 0.8661 22.00MM
Cut Dia Min 1.9690 50.01MM
Flutes/Inserts 6
Insert Size Ic 11
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Hand R/L Right
Insert Style LQ
Fasteners & Connectors
Insert Screw 7002495
