Picture of TUNGALOY TPQ11R040M16.0E04 Milling Cutter 90.0° 1.575 Cutter Diameter Shell Arbor 0.6300 4 Flute

TUNGALOY TPQ11R040M16.0E04 Milling Cutter 90.0° 1.575 Cutter Diameter Shell Arbor 0.6300 4 Flute

ANSI: TPQ11R040M16.0E04

ISO: TPQ11R040M16.0E04

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861285
Delivery date: 3-5 days
$544.25

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Slot Milling, Face Milling
Package Size 1
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Insert Type Negative
Shipping State Illinois
Dimensional Specifications
Cut Dia Max 1.5750 40.01MM
Machine Side Connection Size 0.6299 16.00MM
Depth Of Cut Max 0.3540
Insert Size Ic 11
Machine Side Connection Type Face Mill/Shell Mill
Flutes/Inserts 4
Cut Dia Min 1.5750 40.01MM
Cutter Dia 1.5750 40.01MM
Tool Material Steel
Cutting & Machining Properties
Hand R/L Right
Insert Style LQ
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Fasteners & Connectors
Insert Screw 7002495
