  • TUNGALOY TLFNL3232P16 Stick Tool On Edge Insert Neg,F style, 91deg Approach , Steel Square 1.259 Shank
Picture of TUNGALOY TLFNL3232P16 Stick Tool On Edge Insert Neg,F style, 91deg Approach , Steel Square 1.259 Shank

TUNGALOY TLFNL3232P16 Stick Tool On Edge Insert Neg,F style, 91deg Approach , Steel Square 1.259 Shank

ANSI: TLFNL3232P16

ISO: TLFNL3232P16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6861561
Delivery date: 3-5 days
$184.05

Important Notes

Neg,F style, 91deg Approach

Details

Screw-on clamp toolholder with tangential insert for roughing operation with 93deg approach angle

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Insert Type Negative
Made In USA No
Application Ext.Turning
Package Size 1
Dimensional Specifications
Insert Size Ic 16
Lead Angle 93° F
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 6.6929 170.00MM
Machine Side Connection Size 1.2598 32.00MM
Shank/Pilot Dia 1.2598 32.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Rectagonal
Insert Style LN
Hand R/L Left
Inter/Extern External
