  • TUNGALOY TLBNL24-24 Stick Tool On Edge Insert Neg,B/R style, 75deg Approach , Steel Square 1.500 Shank
Picture of TUNGALOY TLBNL24-24 Stick Tool On Edge Insert Neg,B/R style, 75deg Approach , Steel Square 1.500 Shank

TUNGALOY TLBNL24-24 Stick Tool On Edge Insert Neg,B/R style, 75deg Approach , Steel Square 1.500 Shank

ANSI: TLBNL24-24

ISO: TLBNL24-24

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6865648
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Important Notes

Neg,B/R style, 75deg Approach

Details

Screw-on clamp toolholder with tangential insert for roughing operation with 75deg approach angle

Products specifications
Attribute name Attribute value
General Product Information
Application Ext.Turning
Package Size 1
Insert Application General Purpose
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Insert Size Ic 24
Machine Side Connection Size 1.5000 38.10MM
Overall Len 7.8740 200.00MM
Lead Angle 75°
Tool Material Steel
Machine Side Connection Type Stick Tool
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Rectagonal
Hand R/L Left
Inter/Extern External
Insert Style LN
