Picture of TUNGALOY TID060F12-1.5 6mm Drill Meister Indexable head Drill with flanged Shank

TUNGALOY TID060F12-1.5 6mm Drill Meister Indexable head Drill with flanged Shank

ISO: TID060F12-1.5

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6751935
Delivery date: 3-5 days
$226.50

Cutting Edge Definition

Tool steel is any of various carbon steels and alloy steels that are particularly well-suited to be made into tools and tooling, including cutting tools, dies, hand tools, knives, and others.

Products specifications
Attribute name Attribute value
General Product Information
Application Single Insert Drilling, Insert Drilling
Package Size 1
Made In USA No
Shipping State Illinois
Dimensional Specifications
Flute Length 0.3940 10.01MM
Cut Dia Min 0.2362 6.00MM
Machine Side Connection Size 0.4724 12.00MM
Overall Len 2.6772 68.00MM
Flutes/Inserts 2
Dia Deep 1.5XD
Cut Dia Max 0.2520 6.40MM
Machine Side Connection Type Boring Bar,Weldon
Shank/Pilot Dia 0.4724 12.00MM
Cutter Dia 0.2362 6.00MM
Included Angle 136°
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Cutting Edge Mat Steel
Industry-Specific Applications
Aerospace Yes
Mold Yes
Agricultural YES
Energy Yes
Multi Spindle Yes
Medical Yes
Automotive Yes
Job Shop Yes
