Picture of TUNGALOY THSN12M063B22.0R04 Milling Cutter 88.0° 2.480 Cutter Diameter Shell Arbor 0.8661 4 Flute

TUNGALOY THSN12M063B22.0R04 Milling Cutter 88.0° 2.480 Cutter Diameter Shell Arbor 0.8661 4 Flute

ANSI: THSN12M063B22.0R04

ISO: THSN12M063B22.0R04

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6781885
Delivery date: 3-5 days
$658.25

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert Application Semi Finishing, Roughing
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Face Milling
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 12
Cutter Dia 2.4800 62.99MM
Flutes/Inserts 4
Cut Dia Max 2.5040 63.60MM
Depth Of Cut Max 0.3740
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 0.8661 22.00MM
Cut Dia Min 2.4800 62.99MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Square
Hand R/L Right
Insert Style SN
Fasteners & Connectors
Insert Screw 6816783
