Picture of TUNGALOY THSN12J080B25.4R08 Milling Cutter 88.0° 3.150 Cutter Diameter Shell Arbor 1.0000 8 Flute

TUNGALOY THSN12J080B25.4R08 Milling Cutter 88.0° 3.150 Cutter Diameter Shell Arbor 1.0000 8 Flute

ANSI: THSN12J080B25.4R08

ISO: THSN12J080B25.4R08

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6777928
Delivery date: 3-5 days
$883.25

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling
Package Size 1
Insert Type Negative
Shipping State Illinois
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Made In USA No
Dimensional Specifications
Depth Of Cut Max 0.0197
Tool Material Steel
Flutes/Inserts 8
Cut Dia Max 3.1730 80.59MM
Machine Side Connection Size 1.0000 25.40MM
Cut Dia Min 3.1500 80.01MM
Insert Size Ic 12
Cutter Dia 3.1500 80.01MM
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Style SN
Hand R/L Right
Insert Shape/Cutter Pocket Shape Square
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 6816783
