  • TUNGALOY TFMRND2.50-12-5Z-FL Milling Cutter Button Cutter 2.500 Cutter Diameter Shell Arbor 0.7500 5 Flute
Picture of TUNGALOY TFMRND2.50-12-5Z-FL Milling Cutter Button Cutter 2.500 Cutter Diameter Shell Arbor 0.7500 5 Flute

TUNGALOY TFMRND2.50-12-5Z-FL Milling Cutter Button Cutter 2.500 Cutter Diameter Shell Arbor 0.7500 5 Flute

ANSI: TFMRND2.50-12-5Z-FL

ISO: TFMRND2.50-12-5Z-FL

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6322760
Delivery date: 3-5 days
$722.35

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Face Milling, Round Milling, Pocket Milling
Package Size 1
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 2.0000 50.80MM
Insert Size Ic 12
Cut Dia Max 2.5000 63.50MM - 2-1/2
Machine Side Connection Type Face Mill/Shell Mill
Cutter Dia 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 0.7500 19.05MM
Depth Of Cut Max 0.0790
Tool Material Steel
Flutes/Inserts 5
Cutting & Machining Properties
Insert Style RN
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Round
Hand R/L Right
Fasteners & Connectors
Clamp/Wedge 6198186
Clamp Screw 4350728
