Picture of TUNGALOY SYQBL2020K16 Stick Tool 25.0° Insert Posi,Q/H style, 45deg Approach , Steel Square 0.787 Shank

TUNGALOY SYQBL2020K16 Stick Tool 25.0° Insert Posi,Q/H style, 45deg Approach , Steel Square 0.787 Shank

ANSI: SYQBL2020K16

ISO: SYQBL2020K16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6855991
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Important Notes

Posi,Q/H style, 45deg Approach

Details

Screw-on clamp toolholder with 122.5deg approach angle, for positive 25deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 16 "33"
Machine Side Connection Size 0.7874 20.00MM
Overall Len 4.9213 125.00MM
Lead Angle 122.5°
Clearance Angle 30.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Shank/Pilot Dia 0.7874 20.00MM
Cutting & Machining Properties
Insert Style YW
Insert Shape/Cutter Pocket Shape 25.0°
Inter/Extern External
Hand R/L Left
