Picture of TUNGALOY SYHBL163 Stick Tool 25.0° Insert Posi,H style, 100deg Approach , Steel Square 1.000 Shank

TUNGALOY SYHBL163 Stick Tool 25.0° Insert Posi,H style, 100deg Approach , Steel Square 1.000 Shank

ANSI: SYHBL163

ISO: SYHBL163

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6856615
Delivery date: 3-5 days
$160.10

Important Notes

Posi,H style, 100deg Approach

Details

Screw-on clamp toolholder with 100deg approach angle, for positive 25deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Insert Application General Purpose
Insert Type Negative
Shipping State Illinois
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Shank/Pilot Dia 1.0000 25.40MM
Lead Angle 100°
Machine Side Connection Size 1.0000 25.40MM
Tool Material Steel
Machine Side Connection Type Stick Tool
Clearance Angle 53.0°
Insert Size Ic 16 "33"
Overall Len 6.0000 152.40MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 25.0°
Hand R/L Left
Inter/Extern External
Insert Style YW
