  • TUNGALOY SVQCL2525M16 Stick Tool 35.0° Insert Posi,Q/H style, 45deg Approach , Steel Square 0.984 Shank
Picture of TUNGALOY SVQCL2525M16 Stick Tool 35.0° Insert Posi,Q/H style, 45deg Approach , Steel Square 0.984 Shank

TUNGALOY SVQCL2525M16 Stick Tool 35.0° Insert Posi,Q/H style, 45deg Approach , Steel Square 0.984 Shank

ANSI: SVQCL2525M16

ISO: SVQCL2525M16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807429
Delivery date: 3-5 days
$160.10

Important Notes

Posi,Q/H style, 45deg Approach

Details

Screw-on clamp toolholder with 117.5deg approach angle, for positive 35deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Insert Type Positive
Application Ext.Turning
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Lead Angle 117.5°
Machine Side Connection Type Stick Tool
Machine Side Connection Size 0.9843 25.00MM
Overall Len 5.9055 150.00MM
Clearance Angle 25.0°
Shank/Pilot Dia 0.9843 25.00MM
Insert Size Ic 16 "33"
Tool Material Steel
Cutting & Machining Properties
Hand R/L Left
Insert Style VC
Inter/Extern External
Insert Shape/Cutter Pocket Shape 35.0°
