  • TUNGALOY SVJCR1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank
Picture of TUNGALOY SVJCR1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

TUNGALOY SVJCR1616H16 Stick Tool 35.0° Insert Posi,J style, 93deg Approach , Steel Square 0.629 Shank

ANSI: SVJCR1616H16

ISO: SVJCR1616H16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: TUNGALOY
SKU: TUN6807401
Delivery date: 3-5 days
$127.00

Important Notes

Posi,J style, 93deg Approach

Details

Screw-on clamp toolholder with 93deg approach angle, for positive 35deg rhombic inserts

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Application Ext.Turning
Package Size 1
Dimensional Specifications
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Insert Size Ic 16 "33"
Lead Angle 93°
Clearance Angle 50.0°
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 3.9370 100.00MM
Cutting & Machining Properties
Insert Style VC
Hand R/L Right
Insert Shape/Cutter Pocket Shape 35.0°
Inter/Extern External
